MVCT 102 - Construction Materials

UNIT 1. Material Science:

PART A – Classification of Engineering materials

CLASSIFICATION OF ENGINEERING MATERIALS

There are thousands of materials available for use in engineering applications. Most materials fall into one of three classes that are based on the atomic bonding forces of a particular material. These three classifications are metallic, ceramic and polymeric. Additionally, different materials can be combined to create a composite material. Within each of these classifications, materials are often further organized into groups based on their chemical composition or certain physical or mechanical properties. Composite materials are often grouped by the types of materials combined or the way the materials are arranged together. Below is a list of some of the commonly classification of materials within these four general groups of materials.

Metals Ferrous metals and alloys (irons, carbon steels, alloy steels, stainless steels, tool and die steels) Nonferrous metals and alloys (aluminum, copper, magnesium, nickel, titanium, precious metals, refractory metals, superalloys)	Polymeric Thermoplastics plastics Thermoset plastics Elastomers
Ceramics Glasses Glass ceramics Graphite Diamond	Composites Reinforced plastics Metal-matrix composites Ceramic-matrix composites Sandwich structures Concrete

Metals

Metals account for about two thirds of all the elements and about 24% of the mass of the planet. Metals have useful properties including strength, ductility, high melting points, thermal and electrical conductivity, and toughness. From the periodic table, it can be seen that a large number of the elements are classified as being a metal. A few of the common metals and their typical uses are presented below.

Common Metallic Materials

1. Iron/Steel - Steel alloys are used for strength critical applications

2. Aluminum - Aluminum and its alloys are used because they are easy to form, readily available, inexpensive, and recyclable.

3. Copper - Copper and copper alloys have a number of properties that make them useful, including high electrical and thermal conductivity, high ductility, and good corrosion resistance.

4. Titanium - Titanium alloys are used for strength in higher temperature (~1000° F) application, when component weight is a concern, or when good corrosion resistance is required

5. Nickel - Nickel alloys are used for still higher temperatures (~1500-2000° F) applications or when good corrosion resistance is required.

Ceramics

A ceramic has traditionally been defined as “an inorganic, nonmetallic solid that is prepared from powdered materials, is fabricated into products through the application of heat, and displays such characteristic properties as hardness, strength, low electrical conductivity, and brittleness." The word ceramic comes the from Greek word "keramikos", which means "pottery." They are typically crystalline in nature and are compounds formed between metallic and nonmetallic elements such as aluminum and oxygen (alumina-Al2O3), calcium and oxygen (calcia - CaO), and silicon and nitrogen (silicon nitride-Si3N4).

Depending on their method of formation, ceramics can be dense or lightweight. Typically, they will demonstrate excellent strength and hardness properties; however, they are often brittle in nature. Ceramics can also be formed to serve as electrically conductive materials or insulators. Some ceramics, like superconductors, also display magnetic properties. They are also more resistant to high temperatures and harsh environments than metals and polymers. Due to ceramic materials wide range of properties, they are used for a multitude of applications.

The broad categories or segments that make up the ceramic industry can be classified as:

1. Structural clay products (brick, sewer pipe, roofing and wall tile, flue linings, etc.)

2. White wares (dinnerware, floor and wall tile, electrical porcelain, etc.)

3. Refractories (brick and monolithic products used in metal, glass, cements, ceramics, energy conversion, petroleum, and chemicals industries)

4. Glasses (flat glass (windows), container glass (bottles), pressed and blown glass (dinnerware), glass fibers (home insulation), and advanced/specialty glass (optical fibers))

5. Abrasives (natural (garnet, diamond, etc.) and synthetic (silicon carbide, diamond, fused alumina, etc.) abrasives are used for grinding, cutting, polishing, lapping, or pressure blasting of materials)

6. Cements (for roads, bridges, buildings, dams, and etc.)

7. Advanced ceramics

a. Structural (wear parts, bioceramics, cutting tools, and engine components)

b. Electrical (capacitors, insulators, substrates, integrated circuit packages, piezoelectrics, magnets and superconductors)

c. Coatings (engine components, cutting tools, and industrial wear parts)

d. Chemical and environmental (filters, membranes, catalysts, and catalyst supports)

The atoms in ceramic materials are held together by a chemical bond which will be discussed a bit later. Briefly though, the two most common chemical bonds for ceramic materials are covalent and ionic. Covalent and ionic bonds are much stronger than in metallic bonds and, generally speaking, this is why ceramics are brittle and metals are ductile.

Polymers

A polymeric solid can be thought of as a material that contains many chemically bonded parts or units which themselves are bonded together to form a solid. The word polymer literally means "many parts." Two industrially important polymeric materials are plastics and elastomers. Plastics are a large and varied group of synthetic materials which are processed by forming or molding into shape. Just as there are many types of metals such as aluminum and copper, there are many types of plastics, such as polyethylene and nylon. Elastomers or rubbers can be elastically deformed a large amount when a force is applied to them and can return to their original shape (or almost) when the force is released.

Polymers have many properties that make them attractive to use in certain conditions. Many polymers:

1. are less dense than metals or ceramics,

2. resist atmospheric and other forms of corrosion,

3. offer good compatibility with human tissue, or

4. exhibit excellent resistance to the conduction of electrical current.

The polymer plastics can be divided into two classes, thermoplastics and thermosetting plastics, depending on how they are structurally and chemically bonded. Thermoplastic polymers comprise the four most important commodity materials – polyethylene, polypropylene, polystyrene and polyvinyl chloride. There are also a number of specialized engineering polymers. The term ‘thermoplastic’ indicates that these materials melt on heating and may be processed by a variety of molding and extrusion techniques. Alternately, ‘thermosetting’ polymers cannot be melted or remelted. Thermosetting polymers include alkyds, amino and phenolic resins, epoxies, polyurethanes, and unsaturated polyesters.

Rubber is a natural occurring polymer. However, most polymers are created by engineering the combination of hydrogen and carbon atoms and the arrangement of the chains they form. The polymer molecule is a long chain of covalent-bonded atoms and secondary bonds then hold groups of polymer chains together to form the polymeric material. Polymers are primarily produced from petroleum or natural gas raw products but the use of organic substances is growing. The super-material known as Kevlar is a man-made polymer. Kevlar is used in bullet-proof vests, strong/lightweight frames, and underwater cables that are 20 times stronger than st Composites

Composites

A composite is commonly defined as a combination of two or more distinct materials, each of which retains its own distinctive properties, to create a new material with properties that cannot be achieved by any of the components acting alone. Using this definition, it can be determined that a wide range of engineering materials fall into this category. For example, concrete is a composite because it is a mixture of Portland cement and aggregate. Fiberglass sheet is a composite since it is made of glass fibers imbedded in a polymer.

Composite materials are said to have two phases. The reinforcing phase is the fibers, sheets, or particles that are embedded in the matrix phase. The reinforcing material and the matrix material can be metal, ceramic, or polymer. Typically, reinforcing materials are strong with low densities while the matrix is usually a ductile, or tough, material.

Some of the common classifications of composites are:

1. Reinforced plastics

2. Metal-matrix composites

3. Ceramic-matrix composites

4. Sandwich structures

5. Concrete

Composite materials can take many forms but they can be separated into three categories based on the strengthening mechanism. These categories are dispersion strengthened, particle reinforced and fiber reinforced. Dispersion strengthened composites have a fine distribution of secondary particles in the matrix of the material. These particles impede the mechanisms that allow a material to deform. (These mechanisms include dislocation movement and slip, which will be discussed later). Many metal-matrix composites would fall into the dispersion strengthened composite category. Particle reinforced composites have a large volume fraction of particle dispersed in the matrix and the load is shared by the particles and the matrix. Most commercial ceramics and many filled polymers are particle-reinforced composites. In fiber-reinforced composites, the fiber is the primary load-bearing component. Fiberglass and carbon fiber composites are examples of fiber-reinforced composites.

If the composite is designed and fabricated correctly, it combines the strength of the reinforcement with the toughness of the matrix to achieve a combination of desirable properties not available in any single conventional material. Some composites also offer the advantage of being tailorable so that properties, such as strength and stiffness, can easily be changed by changing amount or orientation of the reinforcement material. The downside is that such composites are often more expensive than conventional materials.
